    JHHG-HQ series SF6 mixed gas recovery and recharge purification separation filling device
    • JHHG-HQ series SF6 mixed gas recovery and recharge purification separation filling device

    JHHG-HQ series SF6 mixed gas recovery and recharge purification separation filling device


    recommendation index:
    Intelligent design, simple and convenient operation
    Recovery and Rapid Separation of SF6/N2 Mixed Gas
    Automatic recognition of cylinder status and automatic stop of filling
    Large flow rate high precision mass flow controller
    • It is used for rapid recovery, purification, separation and filling of sulfur hexafluoride mixed gas

    • It is mainly composed of gas circuit system, vacuum system, evaporation and gasification system, gas pretreatment system, gas recovery and separation system, refrigeration liquefaction model system, exhaust gas treatment system, SF6 gas filling system, dynamic gas distribution system, pressurized gas charging system, gas detection system, gas storage tank and intelligent control system

    • Membrane separation technology or cryogenic solidification separation technology is used to separate the SF6 mixed gas, and the N2 gas is discharged into the atmosphere in a high-purity state after being cycled and infiltrated

    project

    Specifications

    model

    JHHG10-HQ1

    JHHG20-HQ1

    JHHG30-HQ1

    Mixing ratio detection (built-in)

    Detection object

    SF6/N2

    Detection scope

    0~100%(volume fraction)

    check the accuracy

    ±0.5%(volume fraction)

    resolving power

    ±0.01%(volume fraction)

    SFTail gas detection (built-in)

    detection sensitivity

    ≤1 μ L/L

    measurement error

    ≤±5%

    match Air filling

    Gas distribution concentration Range

    0-100%

    Optional gas distribution

    SFOr SF6/NOr  SF6/CF4

    Proportioning accuracy

    ±0.5%V/V%

    Air distribution flow

    ≥15m3/h

    ≥30m3/h

    ≥45m3/h

    O2 mixing amount (volume fraction)

    Not more than 0.05%

    irrigation Charging pressure

    1.5 MPa


    Related recommendations

    JHLK100-HQ Series, High Precision Portable Mixed Gas Leak Detector
